products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Steel Structure Warehouse
Created with Pixso.

Prefabricated Metal Warehouse Steel Structure Workshop Plants Factory Storage Building

Prefabricated Metal Warehouse Steel Structure Workshop Plants Factory Storage Building

Brand Name: LanJing
Model Number: S01
MOQ: 100 Square Meters
Price: US$60.00 100-4,999 Square Meters
Payment Terms: L/C,T/T
Supply Ability: 2, 500t/M
Detail Information
Place of Origin:
China
Secondary Frame:
C&Z Purlin, Brace
Performance:
Safety, Water-Proof, Sound Insulated Hear-Preserva
Roof Cladding:
Steel Sheet /Sandwich Panel
Surface Treatment:
Hot DIP Galvanized Or Painted
HS Code:
7308900000
Connection:
Bolt Connection Or Welded Connection
Wall And Roof Sandwich Panel:
EPS, Rock Wool, Glass Wool, PU
After-sales Service:
Online Technical Support,Onsite Installation
Packaging Details:
Loaded into shipping container
Supply Ability:
2, 500t/M
Highlight:

prefabricated metal warehouse steel

,

prefabricated metal warehouse steel structure

,

prefabricated prefab metal warehouse

Product Description

Prefabricated Metal Warehouse Steel Structure Workshop Plants Factory Storage Building

Prefabricated Steel structure building is one kind of product which can be design as per every proples' different need. So, if you found that follows example pictures is not as same as your want, even it is very different. No matter which kind of building you need, prefabricated warehouse bigger, smaller or multi-storey, just tell me the data or drawing of building what you need. we will provide the exact design, quotation with you as soon as possible.

Prefabricated steel structure is widely used as workshop, warehouse, factory, plants, depot, home storage room, commercial office building, hospital, school buildings, hangar, garage, car parking, stadium, farm poulty broiler layer chicken house, layer hens house,cow shed, sheep shed, farm cow barn, industrial buildings, sectors of Oil & Gas, Mining, Energy dormitory, Site office ect.


Main Structure Column/Beam Q235/Q355 Welded H Section Steel
Welding Automatic Submerged Arc Welding
Rust removing Shot blasting
Surface processing twice primer and twice finish Alkyd paint or hot dip galvanized
High strength bolt Grade 10.9
Substructure Angle brace steel Q235, process and painting
Cross bracing  round bar, steel Q235 process and pre-galvanized
Tie bar round pipe, steel Q235 process and painting or pre-galvanized
Batter brace  round bar, steel Q235 process and pre-galvanized
Ordinary bolt Galvanized bolt
Roof Purlin C channel or Z channel, steel Q235, galvanized
Roof panel (50mm~200mm) Sandwich panel , corrugated galvanized iron sheet
Transparent skylight FRP
Accessories Sealant, self-tapping screw
Edge cover Made of color steel sheet
Gutter Made of steel sheet with thickness 0.8mm, or PVC
Rainspout PVC pipe
Wall Purlin C channel or Z channel, steel Q235, galvanized
Wall panel (50~200mm) Sandwich panel , corrugated galvanized steel sheet
Accessories Sealant, self-tapping screw
Edge cover Made of color steel sheet
Ventilator Unpowered axial-flow ventilator or monitor roof
Door & Window Electric/manual rolling door/sliding door, PVC/ Aluminum alloy window
Wind Resistance Grade 12 Grades
Earthquake-resistance 8 Grades
Structure Usage Up to 50 years
customized service and personalized design are welcomed!!

Prefabricated Metal Warehouse Steel Structure Workshop Plants Factory Storage Building 0Prefabricated Metal Warehouse Steel Structure Workshop Plants Factory Storage Building 1

  • Product Application

Prefabricated Metal Warehouse Steel Structure Workshop Plants Factory Storage Building 2

  • Technical Support

If you have drawings, feel free to share them with us, and the quotation will be based on your drawings. If there are no drawings, our excellent design team will create a  for you according your needs.

Our company can provide a comprehensive ONE-STOP service with customers for their customized solutions including consultation, R&D, design, manufacturing, installation, overseas project supervision and after-sales support.

       Prefabricated Metal Warehouse Steel Structure Workshop Plants Factory Storage Building 3

Prefabricated Metal Warehouse Steel Structure Workshop Plants Factory Storage Building 4


  • Production Process

We have established a procedure to check products at all stages of the manufacturing process, including raw materials, in-process materials, validated or tested materials, and finished goods.

We adhere to the concept of Quality First, Technology Ahead and Continuous Innovation.

Prefabricated Metal Warehouse Steel Structure Workshop Plants Factory Storage Building 5

  • Packaging & Shipping

Steel components are packaged with steel structure pallets at the factory with the codincnumber, which is convenient for customers to unload; Small steel structures arebundled with iron wires and hung with tags.

Prefabricated Metal Warehouse Steel Structure Workshop Plants Factory Storage Building 6


  • Company Profile

Prefabricated Metal Warehouse Steel Structure Workshop Plants Factory Storage Building 7

Prefabricated Metal Warehouse Steel Structure Workshop Plants Factory Storage Building 8

Shandong Lanjing Building & Construction Co., Ltd. is a professional manufacturer for Steel structure building,Container House and Prefab house in China for more than 10 years.
Exported to 100+ countries and completed 500+ projects.

IS09001, BV, SGS, TUV audited
Lanjing Building & Construction offers comprehensive ONE-STOP services, delivering customized solutions that include Consultation, R&D, Design, Manufacturing, Installation, Overseas project supervision and after-sales support.
We specialize in creation of high-quality Steel structure Warehouse, Workshop, High-rise steel fame building and Container house for Labor camp, worker container etc.
We provide steel building to clients in the sectors of Oil & Gas, Mining, Energy dormitory, Site office, Shower container. Toilet Infrastructure and Construction projects Steel Structure built his reputation Reliability and Service.
Our factory is located in Weifang, China, with a factory area of more than 12 hectares ((120.000SOM )and a registered capital of CNY50 Million, after more than 10 years of development, we have strong technical strength and comprehensive product lines.Steel Structure has completed 500+ projects in more than 100 countries, We has built long-term partnerships with different international companies as well as organizations & government.

Main Products

Steel structure Building

Prefabricated container house

Metal Sandwich Panels

Prefabricated Metal Warehouse Steel Structure Workshop Plants Factory Storage Building 9

  • FAQ

Q1: Is your company a factory or trading company?
A: We are manufacturer with foreign trade department, so you can get competitive price as well as professional service. And you are always welcomed to visit our factory at any time.

Q2: What are your main products?
A: We provide steel structure warehouse, workshop, plants,chicken house, prefabricated house, container type house, garage, aircraft hangar, sandwich panels and other construction materials. According to the requirements of different projects and clients, we will supply different designs and steel products.Customized design is available.

Q3: What's the quality assurance you provide and how do you make quality control?
A: Quality-first is our core value. LJ steel structure quality assurance team and quality control team have developed a rigorous quality inspection system based on ISO9001. Testing Laboratory guarantees qualified raw materials and high- standard product.

Q4: Do you provide installation instructions and on-site installation services?
A:Every project will provide the installation instructions, and if you need, we also would like to send our engineer to the local construction site for helping the installation work.

Q5: What should I provide to get a complete quotation?
A: Please provide information as follows:

1.Project location 5.Length (sidewall,m) 9.Window material, style,size
2.Snow load 6.Width (end wall, m) 10.Door material, style,size
3.Wind load 7.Wall Height (eave, m) 11.raining condition
4.Seismic magnitude 8.Middle column allowed or not 12.Crane needed or not
13.other information if necessary
