Steel Structure Warehouse
Created with Pixso.

Customized Prefab Steel Structural Building Workshop Warehouse

Customized Prefab Steel Structural Building Workshop Warehouse

Brand Name: LanJing
Model Number: S01
MOQ: 100 Square Meters
Price: US$60.00 100-4,999 Square Meters
Payment Terms: L/C,T/T
Supply Ability: 2, 500t/M
Detail Information
Place of Origin:
China
Feature:
Anti-Corrosion, Earthquake Resistance, Easy To Install, High Intensity, Recyclable, Green
Application:
Workshop, Warehouse, Platform, Fabricated House, Farm House, Poulty Chicken House, Shed,Garage
Door:
Electric/manual Rolling Door/Sliding Door
Main Frame:
Welded H Steel Beam, Steel Truss
Surface Treatment:
Hot DIP Galvanized Or Painted
HS Code:
7308900000
Connection:
Bolt Connection Or Welded Connection
Wall And Roof Sandwich Panel:
EPS, Rock Wool, Glass Wool, PU
Packaging Details:
Loaded into shipping container
Supply Ability:
2, 500t/M
Highlight:

prefab steel structure warehouse

,

prefab steel warehouse buildings

,

workshop steel structure warehouse

Product Description

Customized Prefab High-Quality Storage Integration Steel Structure Building Workshop Warehouse

Steel structure building is light in weight, high in strength, good in rigidity and plasticity Steel structure warehouse and workshop are very popular in many countries. Because the steel structure system has a strong ability to resist earthquake and horizontal load. And the Installation can be completed quickly without the influence of environmental season.



Steel structures are widely used in warehouse, workshop, commerical office, hospital, hangar, shed, commercial steel building, farm poultry broiler and layer chicken house, sheep shed, pig shed, garage, industrial steel structure, bridge and more.



Item Material Description and surface process

Main steel frame
Column and Beam Q235 or Q355 H section steel with two coats of mid-gray  paint
Purlin Q235 or Q355 Galvanizd C or Z  type  steel
Connecting
Pieces
Tie tube  Q235   Circular Tube with two coats of mid-gray paint
 Knee-Bracing Q235    Galvanizd angle steel
Strutting piece Q235    Galvanizd Circular Tube
Column Bracing Q235  Circular Tube with two coats of mid-gray paint
Horizontal Bracing Q235  Circular Tube with two coats of mid-gray paint
Casing Q235    Galvanized Circular Tube
Door and Window Item Description
Door Roller shutter door or Sliding door
Window PVC Window or aluminum alloy window
Other parts Ventilating device Fan,Ventilation window
Bolt Foundation bolt,High strengthen bolt, Normal bolts
Skylight Glass Fiber Reinforced Plastics
Out/Inner ridge tile  Color sheet
Crane beam Q235 or Q345  H section steel with two coats of mid-gray paint

Customized Prefab Steel Structural Building Workshop Warehouse 0Customized Prefab Steel Structural Building Workshop Warehouse 1

  • Product Application

Light steel structure building, Metal warehouse, workshop,commerical steel structure building, Farm poultry chicken house, brilor chicken house, layer chicken house, Cow shed, Sheep shed, Garage, Hanger. As well as bridge,oil releated steel structure buildings.

Customized Prefab Steel Structural Building Workshop Warehouse 2

  • Technical Support

We boast advanced steel structure production equipment and technology, as well as a team of professional designers. We provide tailored solutions based on your specific requirements, usage, and local climate.

Steps to get a steel building solution
Tell us about
your
project
Receive your customized
solution & budget
Confirm and start
your
project
Share your project requirements, drawings, and ideas as detailed as possible Our team will develop the best solution based on your specifications and provide an buget  After your approval,we'll begin production and manage every aspect of delivery and installation

       Customized Prefab Steel Structural Building Workshop Warehouse 3

Customized Prefab Steel Structural Building Workshop Warehouse 4



  • Production Process

In the steel structure production process, we adhere to strict quality control at every stage, from the procurement of raw materials to the final product's delivery. Our technical team uses advanced production equipment and processes, aligning with international quality standards to ensure that every steel structure product possesses exceptional strength, durability, and stability. Through continuous quality monitoring and meticulous inspection procedures, we ensure that each project meets our clients' high standards, guaranteeing the safety and quality of the construction.

Customized Prefab Steel Structural Building Workshop Warehouse 5

  • Packaging & Shipping

We considered the fragility, weight, and potential risks during transportation of different components when loading the products into the shipping containers, and took appropriate measures to ensure the safe and efficient unloading process for the customers.

Customized Prefab Steel Structural Building Workshop Warehouse 6



  • Company Profile

Customized Prefab Steel Structural Building Workshop Warehouse 7

Customized Prefab Steel Structural Building Workshop Warehouse 8

Lanjing Group, Weifang City of Shandong Province, north of China, with a factory area of more than 12 hectares ((120.000SOM ), is a comprehensive enterprise integrating steel structure design, manufacturing, and installation. With over 20 years of industry experience, the company has always adhered to the philosophy of "quality-oriented, customer first." It is committed to providing customers with efficient, safe and environmentally friendly steel structure solutions. With strong technical expertise and extensive project experience, Lanjing Group has become one of the leading enterprises in the steel structure industry in china.

Main Products

Steel structure Building

Prefabricated container house

Metal Sandwich Panels

Customized Prefab Steel Structural Building Workshop Warehouse 9

  • FAQ

Q1: Is your company a factory or trading company?
A: We are manufacturer with foreign trade department, so you can get competitive price as well as professional service. And you are always welcomed to visit our factory at any time.

Q2: What are your main products?
A: We provide steel structure warehouse, workshop, plants,chicken house, prefabricated house, container type house, garage, aircraft hangar, sandwich panels and other construction materials. According to the requirements of different projects and clients, we will supply different designs and steel products.Customized design is available.

Q3: What's the quality assurance you provide and how do you make quality control?
A: Quality-first is our core value. LJ steel structure quality assurance team and quality control team have developed a rigorous quality inspection system based on ISO9001. Testing Laboratory guarantees qualified raw materials and high- standard product.

Q4: Do you provide installation instructions and on-site installation services?
A:Every project will provide the installation instructions, and if you need, we also would like to send our engineer to the local construction site for helping the installation work.

Q5: What should I provide to get a complete quotation?
A: Please provide information as follows:

1.Project location 5.Length (sidewall,m) 9.Window material, style,size
2.Snow load 6.Width (end wall, m) 10.Door material, style,size
3.Wind load 7.Wall Height (eave, m) 11.raining condition
4.Seismic magnitude 8.Middle column allowed or not 12.Crane needed or not
13.other information if necessary
