Steel Structure Warehouse
Created with Pixso.

Prefabricated Light Steel Frame Steel Structural Building Workshop Metal Warehouse

Prefabricated Light Steel Frame Steel Structural Building Workshop Metal Warehouse

Brand Name: LanJing
Model Number: S01
MOQ: 100 Square Meters
Price: US$60.00 100-4,999 Square Meters
Payment Terms: L/C,T/T
Supply Ability: 2, 500t/M
Detail Information
Place of Origin:
China
Secondary Frame:
C&Z Purlin, Brace
Performance:
Safety, Water-Proof, Sound Insulated Hear-Preserva
Roof Cladding:
Steel Sheet /Sandwich Panel
Surface Treatment:
Hot DIP Galvanized Or Painted
HS Code:
7308900000
Connection:
Bolt Connection Or Welded Connection
Wall And Roof Sandwich Panel:
EPS, Rock Wool, Glass Wool, PU
After-sales Service:
Online Technical Support,Onsite Installation
Packaging Details:
Loaded into shipping container
Supply Ability:
2, 500t/M
Highlight:

prefabricated steel structure warehouse

,

prefabricated steel warehouse buildings

,

factory steel structure warehouse

Product Description

Prefabricated Light Steel Frame Structure Factory Warehouse Workshop Building Metal Warehouse

Prefabricated Steel structure building is one kind of product which can be design as per every proples' different need. So, if you found that follows example pictures is not as same as your want, even it is very different. No matter which kind of building you need, prefabricated warehouse bigger, smaller or multi-storey, just tell me the data or drawing of building what you need. we will provide the exact design, quotation with you as soon as possible.

Prefabricated steel structure is widely used as workshop, warehouse, factory, plants, depot, home storage room, commercial office building, hospital, school buildings, hangar, garage, car parking, stadium, farm poulty broiler layer chicken house, layer hens house,cow shed, sheep shed, farm cow barn, industrial buildings, sectors of Oil & Gas, Mining, Energy dormitory, Site office ect.



Item Material Description and surface process

Main steel frame
Column and Beam Q235 or Q355 H section steel with two coats of mid-gray  paint
Purlin Q235 or Q355 Galvanizd C or Z  type  steel
Connecting
Pieces
Tie tube  Q235   Circular Tube with two coats of mid-gray paint
 Knee-Bracing Q235    Galvanizd angle steel
Strutting piece Q235    Galvanizd Circular Tube
Column Bracing Q235  Circular Tube with two coats of mid-gray paint
Horizontal Bracing Q235  Circular Tube with two coats of mid-gray paint
Casing Q235    Galvanized Circular Tube
Door and Window Item Description
Door Roller shutter door or Sliding door
Window PVC Window or aluminum alloy window
Other parts Ventilating device Fan,Ventilation window
Bolt Foundation bolt,High strengthen bolt, Normal bolts
Skylight Glass Fiber Reinforced Plastics
Out/Inner ridge tile  Color sheet
Crane beam Q235 or Q345  H section steel with two coats of mid-gray paint

Prefabricated Light Steel Frame Steel Structural Building Workshop Metal Warehouse 0Prefabricated Light Steel Frame Steel Structural Building Workshop Metal Warehouse 1

  • Product Application

Prefabricated Light Steel Frame Steel Structural Building Workshop Metal Warehouse 2

  • Technical Support

If you have drawings, feel free to share them with us, and the quotation will be based on your drawings. If there are no drawings, our excellent design team will create a  for you according your needs.

Our company can provide a comprehensive ONE-STOP service with customers for their customized solutions including consultation, R&D, design, manufacturing, installation, overseas project supervision and after-sales support.

Steps to get a steel building solution
Tell us about
your
project
Receive your customized
solution & budget
Confirm and start
your
project
Share your project requirements, drawings, and ideas as detailed as possible Our team will develop the best solution based on your specifications and provide an buget  After your approval,we'll begin production and manage every aspect of delivery and installation

       Prefabricated Light Steel Frame Steel Structural Building Workshop Metal Warehouse 3

Prefabricated Light Steel Frame Steel Structural Building Workshop Metal Warehouse 4



  • Production Process

We have established a procedure to check products at all stages of the manufacturing process, including raw materials, in-process materials, validated or tested materials, and finished goods.

We adhere to the concept of Quality First, Technology Ahead and Continuous Innovation.

Prefabricated Light Steel Frame Steel Structural Building Workshop Metal Warehouse 5

  • Packaging & Shipping

Steel components are packaged with steel structure pallets at the factory with the codincnumber, which is convenient for customers to unload; Small steel structures arebundled with iron wires and hung with tags.

Prefabricated Light Steel Frame Steel Structural Building Workshop Metal Warehouse 6



  • Company Profile

Prefabricated Light Steel Frame Steel Structural Building Workshop Metal Warehouse 7

Prefabricated Light Steel Frame Steel Structural Building Workshop Metal Warehouse 8

Shandong Lanjing Building & Construction Co., Ltd. is a professional manufacturer for Steel structure building,Container House and Prefab house in China for more than 10 years.
Exported to 100+ countries and completed 500+ projects.

IS09001, BV, SGS, TUV audited
Lanjing Building & Construction offers comprehensive ONE-STOP services, delivering customized solutions that include Consultation, R&D, Design, Manufacturing, Installation, Overseas project supervision and after-sales support.
We specialize in creation of high-quality Steel structure Warehouse, Workshop, High-rise steel fame building and Container house for Labor camp, worker container etc.
We provide steel building to clients in the sectors of Oil & Gas, Mining, Energy dormitory, Site office, Shower container. Toilet Infrastructure and Construction projects Steel Structure built his reputation Reliability and Service.
Our factory is located in Weifang, China, with a factory area of more than 12 hectares ((120.000SOM )and a registered capital of CNY50 Million, after more than 10 years of development, we have strong technical strength and comprehensive product lines.Steel Structure has completed 500+ projects in more than 100 countries, We has built long-term partnerships with different international companies as well as organizations & government.

Main Products

Steel structure Building

Prefabricated container house

Metal Sandwich Panels

Prefabricated Light Steel Frame Steel Structural Building Workshop Metal Warehouse 9

  • FAQ

Q1: Is your company a factory or trading company?
A: We are manufacturer with foreign trade department, so you can get competitive price as well as professional service. And you are always welcomed to visit our factory at any time.

Q2: What are your main products?
A: We provide steel structure warehouse, workshop, plants,chicken house, prefabricated house, container type house, garage, aircraft hangar, sandwich panels and other construction materials. According to the requirements of different projects and clients, we will supply different designs and steel products.Customized design is available.

Q3: What's the quality assurance you provide and how do you make quality control?
A: Quality-first is our core value. LJ steel structure quality assurance team and quality control team have developed a rigorous quality inspection system based on ISO9001. Testing Laboratory guarantees qualified raw materials and high- standard product.

Q4: Do you provide installation instructions and on-site installation services?
A:Every project will provide the installation instructions, and if you need, we also would like to send our engineer to the local construction site for helping the installation work.

Q5: What should I provide to get a complete quotation?
A: Please provide information as follows:

1.Project location 5.Length (sidewall,m) 9.Window material, style,size
2.Snow load 6.Width (end wall, m) 10.Door material, style,size
3.Wind load 7.Wall Height (eave, m) 11.raining condition
4.Seismic magnitude 8.Middle column allowed or not 12.Crane needed or not
13.other information if necessary
