Steel Structure Warehouse
Created with Pixso.

Prefab Metal Workshop Light Industrial Steel Structure Warehouse Structural Steel Workshop

Prefab Metal Workshop Light Industrial Steel Structure Warehouse Structural Steel Workshop

Brand Name: LanJing
Model Number: S01
MOQ: 100 Square Meters
Price: US$60.00 100-4,999 Square Meters
Payment Terms: L/C,T/T
Supply Ability: 2, 500t/M
Detail Information
Place of Origin:
China
Application:
Workshop, Warehouse, Platform, Fabricated House, Farm House, Poulty Chicken House, Shed,Garage
Roof Cladding:
Steel Sheet /Sandwich Panel
Surface Treatment:
Hot DIP Galvanized Or Painted
Project Solution Capability:
Graphic Design, 3D Model Design
Software:
CAD, Tekla, Sketchup, Pkpm, Bim
Specification:
Q355b. Q235b
HS Code:
7308900000
Connection:
Bolt Connection Or Welded Connection
Packaging Details:
Loaded into shipping container
Supply Ability:
2, 500t/M
Highlight:

industrial steel structure warehouse

,

prefab steel structure warehouse

,

prefab steel warehouse buildings

Product Description

Prefab Metal Workshop Light Industrial Steel Structure Warehouse Structural Steel Workshop

The construction of prefabricated steel structure products is a crucial technology in modern architecture, known for its efficiency, precision, and sustainability. It has become the preferred choice for industrial factories, commercial buildings, stadiums, and more.

The structures are formed by steel columns, beams, bracing, and purlins. All components are prefabricated in the workshop and ready for assembly. Wall and roof materials can be made of single steel sheets or sandwich panels. All steel structure components are connected by bolts, making installation easy and quick to complete.


Item Material Description and surface process

Main steel frame
Column and Beam Q235 or Q355 H section steel with two coats of mid-gray  paint
Purlin Q235 or Q355 Galvanizd C or Z  type  steel
Connecting
Pieces
Tie tube  Q235   Circular Tube with two coats of mid-gray paint
 Knee-Bracing Q235    Galvanizd angle steel
Strutting piece Q235    Galvanizd Circular Tube
Column Bracing Q235  Circular Tube with two coats of mid-gray paint
Horizontal Bracing Q235  Circular Tube with two coats of mid-gray paint
Casing Q235    Galvanized Circular Tube
Door and Window Item Description
Door Roller shutter door or Sliding door
Window PVC Window or aluminum alloy window
Other parts Ventilating device Fan,Ventilation window
Bolt Foundation bolt,High strengthen bolt, Normal bolts
Skylight Glass Fiber Reinforced Plastics
Out/Inner ridge tile  Color sheet
Crane beam Q235 or Q345  H section steel with two coats of mid-gray paint

Prefab Metal Workshop Light Industrial Steel Structure Warehouse Structural Steel Workshop 0Prefab Metal Workshop Light Industrial Steel Structure Warehouse Structural Steel Workshop 1

  • Product Application

Prefabricated steel structure building is widely used as workshop, warehouse, factory, plants, depot, home storage room, commercial office building, hospital, school buildings, hangar, garage, car parking, stadium, farm poulty broiler layer chicken house, layer hens house,cow shed, sheep shed, farm cow barn, industrial buildings, sectors of Oil & Gas, Mining, Energy dormitory, Site office ect.

Prefab Metal Workshop Light Industrial Steel Structure Warehouse Structural Steel Workshop 2

  • Technical Support

Our company can provide one-stop solution including the construction drawings and calculation with you .We have a professional technical team that offers the best steel structure building solutions depands on the specific requirements of our clients.

If you have drawings, feel free to share them with us, and the quotation will be based on your drawings. If there are no drawings, our excellent design team will create a steel structure workshop warehouse design for you.

Steps to get a steel building solution
Tell us about
your
project
Receive your customized
solution & budget
Confirm and start
your
project
Share your project requirements, drawings, and ideas as detailed as possible Our team will develop the best solution based on your specifications and provide an buget  After your approval,we'll begin production and manage every aspect of delivery and installation

       Prefab Metal Workshop Light Industrial Steel Structure Warehouse Structural Steel Workshop 3

Prefab Metal Workshop Light Industrial Steel Structure Warehouse Structural Steel Workshop 4


  • Production Process

We have established a procedure to check products at all stages of the manufacturing process, including raw materials, in-process materials, validated or tested materials, and finished goods.

Prefab Metal Workshop Light Industrial Steel Structure Warehouse Structural Steel Workshop 5

  • Packaging & Shipping

We have established a procedure to check products at all stages of the manufacturing process, including raw materials, in-process materials, validated or tested materials, and finished goods.

Prefab Metal Workshop Light Industrial Steel Structure Warehouse Structural Steel Workshop 6


  • Company Profile

Prefab Metal Workshop Light Industrial Steel Structure Warehouse Structural Steel Workshop 7

Prefab Metal Workshop Light Industrial Steel Structure Warehouse Structural Steel Workshop 8

Shandong Lanjing Building & Construction Co., Ltd. is a professional manufacturer for Steel structure building,Container House and Prefab house in China for more than 10 years.
Exported to 100+ countries and completed 500+ projects.

IS09001, BV, SGS, TUV audited
Lanjing Building & Construction offers comprehensive ONE-STOP services, delivering customized solutions that include Consultation, R&D, Design, Manufacturing, Installation, Overseas project supervision and after-sales support.
We specialize in creation of high-quality Steel structure Warehouse, Workshop, High-rise steel fame building and Container house for Labor camp, worker container etc.
We provide steel building to clients in the sectors of Oil & Gas, Mining, Energy dormitory, Site office, Shower container. Toilet Infrastructure and Construction projects Steel Structure built his reputation Reliability and Service.
Our factory is located in Weifang, China, with a factory area of more than 12 hectares ((120.000SOM )and a registered capital of CNY50 Million, after more than 10 years of development, we have strong technical strength and comprehensive product lines.Steel Structure has completed 500+ projects in more than 100 countries, We has built long-term partnerships with different international companies as well as organizations & government.

Main Products

Steel structure Building

Prefabricated container house

Metal Sandwich Panels

Prefab Metal Workshop Light Industrial Steel Structure Warehouse Structural Steel Workshop 9

  • FAQ

Q1: Is your company a factory or trading company?
A: We are manufacturer with foreign trade department, so you can get competitive price as well as professional service. And you are always welcomed to visit our factory at any time.

Q2: What are your main products?
A: We provide steel structure warehouse, workshop, plants,chicken house, prefabricated house, container type house, garage, aircraft hangar, sandwich panels and other construction materials. According to the requirements of different projects and clients, we will supply different designs and steel products.Customized design is available.

Q3: What's the quality assurance you provide and how do you make quality control?
A: Quality-first is our core value. LJ steel structure quality assurance team and quality control team have developed a rigorous quality inspection system based on ISO9001. Testing Laboratory guarantees qualified raw materials and high- standard product.

Q4: Do you provide installation instructions and on-site installation services?
A:Every project will provide the installation instructions, and if you need, we also would like to send our engineer to the local construction site for helping the installation work.

Q5: What should I provide to get a complete quotation?
A: Please provide information as follows:

1.Project location 5.Length (sidewall,m) 9.Window material, style,size
2.Snow load 6.Width (end wall, m) 10.Door material, style,size
3.Wind load 7.Wall Height (eave, m) 11.raining condition
4.Seismic magnitude 8.Middle column allowed or not 12.Crane needed or not
13.other information if necessary
