products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Steel Structure Warehouse
Created with Pixso.

Fast Assembly Prefabricated Light Steel Structure Building Workshop Warehouse Metal Warehouse Storage Warehouse

Fast Assembly Prefabricated Light Steel Structure Building Workshop Warehouse Metal Warehouse Storage Warehouse

Brand Name: LanJing
Model Number: S01
MOQ: 100 Square Meters
Price: US$60.00 100-4,999 Square Meters
Payment Terms: L/C,T/T
Supply Ability: 2, 500t/M
Detail Information
Place of Origin:
China
Software:
CAD, Tekla, Sketchup, Pkpm, Bim
Wall Color:
White, Blue, Optional Colors
Transport Package:
Loaded Into Shipping Container
Specification:
Q355b. Q235b
HS Code:
7308900000
Production Capacity:
2, 500t/M
Packaging Details:
Loaded into shipping container
Supply Ability:
2, 500t/M
Highlight:

prefabricated steel structure warehouse

,

prefabricated steel warehouse buildings

,

workshop steel structure warehouse

Product Description

Fast Assembly Prefabricated Light Steel Structure Building Workshop Warehouse Metal Warehouse Storage Warehouse

The steel structure building is a product that can be customized according to each client's specific needs. If you find that the example pictures we provided are not exactly what you're looking for, even if they are completely different. No matter what kind of building you need—whether it's a prefabricated house, warehouse, workshop, factory, large or small, or multi-storey—just provide us with the necessary details or drawings of the building you require. We will create the exact design, quotation, and rendering for you as soon as possible.

Steel structures can be used for a variety of purposes, including warehouse, workshop, office, hospital, hangar, shed, commercial steel building, farm poultry broiler/layer chicken house, sheep shed, pig shed, garage and more.


Item Material Description and surface process

Main steel frame
Column and Beam Q235 or Q355 H section steel with two coats of mid-gray  paint
Purlin Q235 or Q355 Galvanizd C or Z  type  steel
Connecting
Pieces
Tie tube  Q235   Circular Tube with two coats of mid-gray paint
 Knee-Bracing Q235    Galvanizd angle steel
Strutting piece Q235    Galvanizd Circular Tube
Column Bracing Q235  Circular Tube with two coats of mid-gray paint
Horizontal Bracing Q235  Circular Tube with two coats of mid-gray paint
Casing Q235    Galvanized Circular Tube
Door and Window Item Description
Door Roller shutter door or Sliding door
Window PVC Window or aluminum alloy window
Other parts Ventilating device Fan,Ventilation window
Bolt Foundation bolt,High strengthen bolt, Normal bolts
Skylight Glass Fiber Reinforced Plastics
Out/Inner ridge tile  Color sheet
Crane beam Q235 or Q345  H section steel with two coats of mid-gray paint

Fast Assembly Prefabricated Light Steel Structure Building Workshop Warehouse Metal Warehouse Storage Warehouse 0Fast Assembly Prefabricated Light Steel Structure Building Workshop Warehouse Metal Warehouse Storage Warehouse 1

  • Product Application

Steel structures are adaptable and can serve multiple functions, including serving as warehouse, workshop, hangar, storage, shed, commercial buildings, office, hospital, school, steel structure farm poultry chicken house for broiler or layer, barn for sheep, cow barn, garage, and various other uses.

Fast Assembly Prefabricated Light Steel Structure Building Workshop Warehouse Metal Warehouse Storage Warehouse 2

  • Technical Support

If you have drawings, welcome to share drawings with us, quoation will be done based your drawings. Our excellent design team will provide you with the plan and quotation with you according your needs.

1) Customized design is welcomed.

2) In order to give you an exactly quotation and drawings, please let us know length, width, eave height and local weather. We will quote for you promptly.

Steps to get a steel building solution
Tell us about
your
project
Receive your customized
solution & budget
Confirm and start
your
project
Share your project requirements, drawings, and ideas as detailed as possible Our team will develop the best solution based on your specifications and provide an buget  After your approval,we'll begin production and manage every aspect of delivery and installation

       Fast Assembly Prefabricated Light Steel Structure Building Workshop Warehouse Metal Warehouse Storage Warehouse 3

Fast Assembly Prefabricated Light Steel Structure Building Workshop Warehouse Metal Warehouse Storage Warehouse 4


  • Production Process

In the steel structure production process, we adhere to strict quality control at every stage, from the procurement of raw materials to the final product's delivery. Our technical team uses advanced production equipment and processes, aligning with international quality standards to ensure that every steel structure product possesses exceptional strength, durability, and stability. Through continuous quality monitoring and meticulous inspection procedures, we ensure that each project meets our clients' high standards, guaranteeing the safety and quality of the construction.

Fast Assembly Prefabricated Light Steel Structure Building Workshop Warehouse Metal Warehouse Storage Warehouse 5

  • Packaging & Shipping

We considered the fragility, weight, and potential risks during transportation of different components when loading the products into the shipping containers, and took appropriate measures to ensure the safe and efficient unloading process for the customers.

Fast Assembly Prefabricated Light Steel Structure Building Workshop Warehouse Metal Warehouse Storage Warehouse 6


  • Company Profile

Fast Assembly Prefabricated Light Steel Structure Building Workshop Warehouse Metal Warehouse Storage Warehouse 7

Fast Assembly Prefabricated Light Steel Structure Building Workshop Warehouse Metal Warehouse Storage Warehouse 8

Lanjing Group is a professional company specializing in steel structure buildings and prefabricated houses. Located in Shandong Province, China, the company covers an area of more than 12 hectares.

With over 10 years of production experience, we are a well-known steel structure manufacturer in China. Our products are sold nationwide and exported to more than 100 countries and regions.

Lanjing Group will uphold the philosophy of "Quality First, Customer Foremost," providing the best products and services to global clients. We look forward to collaborating with more international partners to jointly promote the development of the global construction industry.

Main Products

Steel structure Building

Prefabricated container house

Metal Sandwich Panels

Fast Assembly Prefabricated Light Steel Structure Building Workshop Warehouse Metal Warehouse Storage Warehouse 9

  • FAQ

Q1: Is your company a factory or trading company?
A: We are manufacturer with foreign trade department, so you can get competitive price as well as professional service. And you are always welcomed to visit our factory at any time.

Q2: What are your main products?
A: We provide steel structure warehouse, workshop, plants,chicken house, prefabricated house, container type house, garage, aircraft hangar, sandwich panels and other construction materials. According to the requirements of different projects and clients, we will supply different designs and steel products.Customized design is available.

Q3: What's the quality assurance you provide and how do you make quality control?
A: Quality-first is our core value. LJ steel structure quality assurance team and quality control team have developed a rigorous quality inspection system based on ISO9001. Testing Laboratory guarantees qualified raw materials and high- standard product.

Q4: Do you provide installation instructions and on-site installation services?
A:Every project will provide the installation instructions, and if you need, we also would like to send our engineer to the local construction site for helping the installation work.

Q5: What should I provide to get a complete quotation?
A: Please provide information as follows:

1.Project location 5.Length (sidewall,m) 9.Window material, style,size
2.Snow load 6.Width (end wall, m) 10.Door material, style,size
3.Wind load 7.Wall Height (eave, m) 11.raining condition
4.Seismic magnitude 8.Middle column allowed or not 12.Crane needed or not
13.other information if necessary
