Brand Name: | LanJing |
Model Number: | S01 |
MOQ: | 100 Square Meters |
Price: | US$60.00 100-4,999 Square Meters |
Payment Terms: | L/C,T/T |
Supply Ability: | 2, 500t/M |
Support Installation Prefab Structural Steel Frame Structure Building Workshop Warehouse Metal Warehouse Shed Storage Standard Design
Prefabricated Steel frame buildings are increasingly popular due to the speed of their install, sustainability aspects and affordability. Steel structures can be a very cost-effective way to give yourself more space.
Name | Steel structuree building | ||
Dimensions | Length | H beam: 4000-15000mm | |
Thickness: | web plate: 6-32mm wing plate: 6-40mm |
||
Height | 200-1200mm | ||
Color | According to customers | ||
Size | MOQ is 200 m2, width * length * eave height | ||
Advantages |
1. Lower cost but beautiful outlook. 7.Environmentally Friendly 8.Recyclable |
||
Main components | Base | Cement and steel foundation bolts | |
Main frame | H beam | ||
Material | Q235B, Q345B or others as buyers' requests. | ||
Purlin | C or Z purlin: Size from C120~C320, Z100~Z20 | ||
Bracing | X-type or other type bracing made from angle, round pipe | ||
Bolt | Plain bolt and High-strenth bolt | ||
Roof & wall | Sandwich panel or color plate | ||
Door | Sliding or rolling door | ||
Window | Aluminium alloy window | ||
Surface | Two lays of Anti-rust Painting or Hot Dip Galvanized | ||
Sheet | 0.5mm or 0.6mm galvanized sheet | ||
Accessories | Semi-transparent skylight belts, Ventilators,down pipe, Glavanized gutter, etc | ||
Usages |
1. Steel structure workshop, warehouse, plant, shed, storage, factory 6. Steel structure industrial building 7.Commercial steel structure building 8.Steel Structure Hangar |
||
Packing |
Steel components are packaged with iron pallets at the factory with the coding number, which is convenient for customers to unload; Small steel structures are bundled with iron wires and hung with tags. Fasteners are packed in wooden cases The upper layer of the color-coated roof and wall panel is covered with plastic film, and the maintenance edge is wrapped with plastic film and labelled. |
||
Drawing | According to drawings or according to customer ' s requirement. | ||
Design Parameters |
If you need we design for you, please supply us the following parameter 5) Brickwall needed or not If yes, 1.2m high or 1.5m high? or other? 6) Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; If not, the metal steel sheets will be ok. |
Steel is strong, versatile, and used in many types of buildings because it has many benefits.
Factory and Warehouse: Steel is commonly used for industrial buildings that need large open spaces.
Commerical Shop and Office: Steel structure building can be used in mall, supermarket, and office building because it supports large areas and tall structures.
Sports Stadiums and sport hall: Steel structure building can be used for stadium because it can span large areas without extra support. Bridge: Steel is used to build bridges because it is light and strong.
Airport and Train Station: Steel is used in these places because it provides large open spaces.
Home and Apartment: Steel structure can also used in residential buildings, especially high rise buildings.
In short, steel structures are adaptable and can serve multiple functions, including serving as warehouse, workshop, hangar, storage, shed, commercial buildings, hotel, office, hospital, school, stadium, exhibtion hall, steel structure sports hall, steel structure farm poultry chicken house for broiler or layer, barn for sheep, cow barn, garage, and various other uses.
Steel structure building is one kind of product which can be design as per every proples' different needs.
So, if you found that follows example pictures is not as same as your want, even it is very different.
Don't worried, no matter which kind of building you need,prefabricated houseswarehouse bigger, smaller or multi-storey, just tell me the data or drawing of building what you need.
We will make the exact design, quotation and rendering for you as soon as we can.
In the steel structure production process, we adhere to strict quality control at every stage, from the procurement of raw materials to the final product's delivery. Our technical team uses advanced production equipment and processes, aligning with international quality standards to ensure that every steel structure product possesses exceptional strength, durability, and stability. Through continuous quality monitoring and meticulous inspection procedures, we ensure that each project meets our clients' high standards, guaranteeing the safety and quality of the construction.
Steel components are packaged with steel structure pallets at the factory with the codincnumber, which is convenient for customers to unload: Small steel structures arebundled with iron wires and hung with tags.
Shandong Lanjing Building & Construction Co., Ltd. is a professional manufacturer for Steel structure building,Container House and Prefab house in China for more than 10 years.
Exported to 100+ countries and completed 500+ projects.
IS09001, BV, SGS, TUV audited
Lanjing Building & Construction offers comprehensive ONE-STOP services, delivering customized solutions that include Consultation, R&D, Design, Manufacturing, Installation, Overseas project supervision and after-sales support.
We specialize in creation of high-quality Steel structure Warehouse, Workshop, High-rise steel fame building and Container house for Labor camp, worker container etc.
We provide steel building to clients in the sectors of Oil & Gas, Mining, Energy dormitory, Site office, Shower container. Toilet Infrastructure and Construction projects Steel Structure built his reputation Reliability and Service.
Our factory is located in Weifang, China, with a factory area of more than 12 hectares ((120.000SOM )and a registered capital of CNY50 Million, after more than 10 years of development, we have strong technical strength and comprehensive product lines.Steel Structure has completed 500+ projects in more than 100 countries, We has built long-term partnerships with different international companies as well as organizations & government.
Q1: Is your company a factory or trading company?
A: We are manufacturer with foreign trade department, so you can get competitive price as well as professional service. And you are always welcomed to visit our factory at any time.
Q2: What are your main products?
A: We provide steel structure warehouse, workshop, plants,chicken house, prefabricated house, container type house, garage, aircraft hangar, sandwich panels and other construction materials. According to the requirements of different projects and clients, we will supply different designs and steel products.Customized design is available.
Q3: What's the quality assurance you provide and how do you make quality control?
A: Quality-first is our core value. LJ steel structure quality assurance team and quality control team have developed a rigorous quality inspection system based on ISO9001. Testing Laboratory guarantees qualified raw materials and high- standard product.
Q4: Do you provide installation instructions and on-site installation services?
A:Every project will provide the installation instructions, and if you need, we also would like to send our engineer to the local construction site for helping the installation work.
Q5: What should I provide to get a complete quotation?
A: Please provide information as follows:
1.Project location | 5.Length (sidewall,m) | 9.Window material, style,size |
2.Snow load | 6.Width (end wall, m) | 10.Door material, style,size |
3.Wind load | 7.Wall Height (eave, m) | 11.raining condition |
4.Seismic magnitude | 8.Middle column allowed or not | 12.Crane needed or not |
13.other information if necessary |
