Steel Structure Warehouse
Created with Pixso.

Prefab Light Structural Steel Workshop Building Warehouse Metal Warehouse

Prefab Light Structural Steel Workshop Building Warehouse Metal Warehouse

Brand Name: LanJing
Model Number: S01
MOQ: 100 Square Meters
Price: US$60.00 100-4,999 Square Meters
Payment Terms: L/C,T/T
Supply Ability: 2, 500t/M
Detail Information
Place of Origin:
China
Feature:
Anti-Corrosion, Earthquake Resistance, Easy To Install, High Intensity, Recyclable, Green
Install:
Online Guidance, Support Installation
Door:
Electric/manual Rolling Door/Sliding Door
Main Frame:
Welded H Steel Beam, Steel Truss
Secondary Frame:
C&Z Purlin, Brace
Roof Cladding:
Steel Sheet /Sandwich Panel
Surface Treatment:
Hot DIP Galvanized Or Painted
After-sales Service:
Online Technical Support,Onsite Installation
Packaging Details:
Loaded into shipping container
Supply Ability:
2, 500t/M
Highlight:

prefab steel structure warehouse

,

prefab steel warehouse buildings

,

workshop steel structure warehouse

Product Description

Prefab Light Structural Steel Workshop Building Warehouse Metal Warehouse

Customized Design Solution: Our product offers a tailored design solution that meets the specific needs of our clients, whether it's for a warehouse, office space, or any other purpose.
Durable and Long-Lasting: With a service life of 50 years, this prefabricated steel structure warehouse is built to withstand various harsh weather conditions, including wind, snow, and seismic activity.
Easy Installation: Our product features a bolt connection system, making it easy to assemble and install, saving time and labor costs for our clients.
Multi-Standard Compliance: Our product complies with multiple international standards, including GB, ASTM, DIN, JIS, AISI, and BS, ensuring that it meets the requirements of clients from different regions.
Comprehensive After-Sale Service: We offer a range of after-sale services, including online technical support, onsite installation, training, and inspection, to ensure that our clients receive the best possible support and maintenance for their product.


Name Steel structuree building
Dimensions Length H beam: 4000-15000mm
Thickness: web plate: 6-32mm
wing plate: 6-40mm

Height 200-1200mm
Color According to customers
Size MOQ is 200 m2, width * length * eave height
Advantages 1. Lower cost but beautiful outlook.
2. High safety performance.
3. easy to assemble and dismantle
4. manufacture under complete quality control system---ISO9001
5. installation with instruction of experienced engineers
6. Light and Strong

7.Environmentally Friendly

8.Recyclable

Main components Base Cement and steel foundation bolts
Main frame H beam
Material Q235B, Q345B or others as buyers' requests.
Purlin C or  Z purlin: Size from C120~C320, Z100~Z20
Bracing X-type or other type bracing made from angle, round pipe
Bolt Plain bolt and High-strenth bolt
Roof & wall Sandwich panel or color plate
Door Sliding or rolling door
Window Aluminium alloy window
Surface Two lays of Anti-rust Painting or Hot Dip Galvanized
Sheet 0.5mm or 0.6mm galvanized sheet
Accessories Semi-transparent skylight belts, Ventilators,down pipe, Glavanized gutter, etc
Usages

1. Steel structure workshop, warehouse, plant, shed, storage, factory
2. Steel structure frame structure
3. Farm poultry house chicken cow sheep
4. Portal frame products
5. High rise building project

6. Steel structure industrial building

7.Commercial steel structure building

8.Steel Structure Hangar


Packing

Steel components are packaged with iron pallets at the factory with the coding number, which is convenient for customers to unload;

Small steel structures are bundled with iron wires and hung with tags.

Fasteners are packed in wooden cases

The upper layer of the color-coated roof and wall panel is covered with plastic film, and the maintenance edge is wrapped with plastic film and labelled.


Drawing According to drawings or according to customer ' s requirement.

Design Parameters

If you need we design for you, please supply us the following parameter
together with detail size:
1) length, width, height, eave height, roof pitch, etc
2) wind load, snow load, raining condition, aseismatic requirements, etc
4) Demands for doors and windows

5) Brickwall needed or not If yes, 1.2m high or 1.5m high? or other?

6) Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; If not, the metal steel sheets will be ok.
7)Other information if necessary


Prefab Light Structural Steel Workshop Building Warehouse Metal Warehouse 0Prefab Light Structural Steel Workshop Building Warehouse Metal Warehouse 1

  • Product Application

Steel structure is widely used as workshop, warehouse, factory, plants, depot, home storage room, commercial office building, hospital, school buildings, hangar, garage, car parking, stadium, farm poulty broiler layer chicken house, layer hens house,cow shed, sheep shed, farm cow barn ect.

Prefab Light Structural Steel Workshop Building Warehouse Metal Warehouse 2

  • Technical Support

Our company can provide one-stop solution including the construction drawings and calculation with you .We have a professional technical team that offers the best steel structure building solutions depands on the specific requirements of our clients.

With help of modern designing soft wares such as AUTOCAD, PKPM, 3D3S, SAP2000, TSSD, Tekla Structures (Xsteel), 3DS MAX ,We provide full designing and detailing service to all cstomers.
( Single span, double span, multi span, single slope, double slope, multi slope etc. )

       Prefab Light Structural Steel Workshop Building Warehouse Metal Warehouse 3

Prefab Light Structural Steel Workshop Building Warehouse Metal Warehouse 4


  • Production Process

We have established a procedure to check products at all stages of the manufacturing process, including raw materials, in-process materials, validated or tested materials, and finished goods.

Prefab Light Structural Steel Workshop Building Warehouse Metal Warehouse 5

  • Packaging & Shipping

Steel components are packaged with steel structure pallets at the factory with the codincnumber, which is convenient for customers to unload; Small steel structures arebundled with iron wires and hung with tags.

Prefab Light Structural Steel Workshop Building Warehouse Metal Warehouse 6


  • Company Profile

Prefab Light Structural Steel Workshop Building Warehouse Metal Warehouse 7

Prefab Light Structural Steel Workshop Building Warehouse Metal Warehouse 8


Lanjing Group is a professional company specializing in steel structure buildings and prefabricated houses. Located in Shandong Province, China, the company covers an area of more than 12 hectares.

With over 10 years of production experience, we are a well-known steel structure manufacturer in China. Our products are sold nationwide and exported to more than 100 countries and regions.

We boast advanced steel structure production equipment and technology, as well as a team of professional designers. We provide tailored solutions based on your specific requirements, usage, and local climate.

ducts

Steel structure Building

Prefabricated container house

Metal Sandwich Panels

Prefab Light Structural Steel Workshop Building Warehouse Metal Warehouse 9

  • FAQ

Q1: Is your company a factory or trading company?
A: We are manufacturer with foreign trade department, so you can get competitive price as well as professional service. And you are always welcomed to visit our factory at any time.

Q2: What are your main products?
A: We provide steel structure warehouse, workshop, plants,chicken house, prefabricated house, container type house, garage, aircraft hangar, sandwich panels and other construction materials. According to the requirements of different projects and clients, we will supply different designs and steel products.Customized design is available.

Q3: What's the quality assurance you provide and how do you make quality control?
A: Quality-first is our core value. LJ steel structure quality assurance team and quality control team have developed a rigorous quality inspection system based on ISO9001. Testing Laboratory guarantees qualified raw materials and high- standard product.

Q4: Do you provide installation instructions and on-site installation services?
A:Every project will provide the installation instructions, and if you need, we also would like to send our engineer to the local construction site for helping the installation work.

Q5: What should I provide to get a complete quotation?
A: Please provide information as follows:

1.Project location 5.Length (sidewall,m) 9.Window material, style,size
2.Snow load 6.Width (end wall, m) 10.Door material, style,size
3.Wind load 7.Wall Height (eave, m) 11.raining condition
4.Seismic magnitude 8.Middle column allowed or not 12.Crane needed or not
13.other information if necessary
