Steel Structure Warehouse
Created with Pixso.

Cheap High Quality Prefabricated Steel Structure Warehouse Building Garage Shed Workshop

Cheap High Quality Prefabricated Steel Structure Warehouse Building Garage Shed Workshop

Brand Name: LanJing
Model Number: S01
MOQ: 100 Square Meters
Price: US$60.00 100-4,999 Square Meters
Payment Terms: L/C,T/T
Supply Ability: 2, 500t/M
Detail Information
Place of Origin:
China
Feature:
Anti-Corrosion, Earthquake Resistance, Easy To Install, High Intensity, Recyclable, Green
Install:
Online Guidance, Support Installation
Drawing:
Design The Drawing As Your Demand
Standard:
GB, ASTM, DIN, JIS, AISI, BS
Application:
Workshop, Warehouse, Platform, Fabricated House, Farm House, Poulty Chicken House, Shed,Garage
Door:
Electric/manual Rolling Door/Sliding Door
Main Frame:
Welded H Steel Beam, Steel Truss
Secondary Frame:
C&Z Purlin, Brace
Performance:
Safety, Water-Proof, Sound Insulated Hear-Preserva
Roof Cladding:
Steel Sheet /Sandwich Panel
Surface Treatment:
Hot DIP Galvanized Or Painted
Environment Protection:
Environmental Friendly Material
Project Solution Capability:
Graphic Design, 3D Model Design, Total Solution Fo
Software:
CAD, Tekla, Sketchup, Pkpm, Bim
Wall Color:
White, Blue, Optional Colors
Transport Package:
Loaded Into Shipping Container
Specification:
Q355b. Q235b
HS Code:
7308900000
Production Capacity:
2, 500t/M
Certification:
ISO, CE, BV, SGS
Warranty:
30 Years Limited Service Life
Connection:
Bolt Connection Or Welded Connection
Usage Life:
50 Years
Wall And Roof Sandwich Panel:
EPS, Rock Wool, Glass Wool, PU
Rain Spout:
PVC
Lighting:
Plane Skylight
Option:
Skylight Belt, Ventilation Fitting, Gutter, Crane
Type:
Portal Frame, Frame Construction
Delivery Time:
Normally 30-45 Days After Shop Drawing Approved
After-sales Service:
Online Technical Support,Onsite Installation
Customization:
Available
Packaging Details:
Loaded into shipping container
Supply Ability:
2, 500t/M
Highlight:

prefabricated steel structure warehouse building

,

building garage shed workshop

,

high quality prefabricated steel structure warehouse

Product Description

Cheap High Quality Prefabricated Steel Structure Warehouse Building Garage Shed Workshop

A steel structure warehouse/workshop refers to a building where the main load-bearing components are made of steel, including primary members, secondary members, roof and wall sheeting, all interconnected with various other building components. These buildings can be equipped with different structural and non-structural additions, such as skylights, wall lights, turbo vents, ridge ventilators, louvers, roof monitors, doors, windows, trusses, mezzanine floors, fascias, canopies, crane systems, insulation, etc.

Steel structures can be used for a variety of purposes, including warehouse, workshop, office, hospital, hangar, shed, commercial steel building, farm poultry broiler/layer chicken house, sheep shed, pig shed, garage and more.


Name Steel structuree building
Dimensions Length H beam: 4000-15000mm
Thickness: web plate: 6-32mm
wing plate: 6-40mm
Height 200-1200mm
Color According to customers
Size MOQ is 200 m2, width * length * eave height
Advantages

1. Lower cost but beautiful outlook.
2. High safety performance.
3. easy to assemble and dismantle
4. manufacture under complete quality control system
5. installation with instruction of experienced engineers
6. Light and Strong

7.Environmentally Friendly

8.Recyclable

Main components Base Cement and steel foundation bolts
Main frame H beam
Material Q235B, Q345B or others as buyers' requests.
Purlin C or  Z purlin: Size from C120~C320, Z100~Z20
Bracing X-type or other type bracing made from angle, round pipe
Bolt Plain bolt and High-strenth bolt
Roof & wall Sandwich panel or color plate
Door Sliding or rolling door
Window Aluminium alloy window
Surface Two lays of Anti-rust Painting or Hot Dip Galvanized
Sheet 0.5mm or 0.6mm galvanized sheet
Accessories Semi-transparent skylight belts, Ventilators,down pipe, Glavanized gutter, etc
Usages

1. Steel structure workshop, warehouse, plant, shed, storage, factory
2. Steel structure frame structure
3. Farm poultry house chicken cow sheep
4. Portal frame products
5. High rise building project

6. Steel structure industrial building

7.Commercial steel structure building

8.Steel Structure Hangar

Packing

Steel components are packaged with iron pallets at the factory with the coding number, which is convenient for customers to unload;

Small steel structures are bundled with iron wires and hung with tags.

Fasteners are packed in wooden cases

The upper layer of the color-coated roof and wall panel is covered with plastic film, and the maintenance edge is wrapped with plastic film and labelled.

Drawing According to drawings or according to customer ' s requirement.

Design Parameters

If you need we design for you, please supply us the following parameter
together with detail size:
1) length, width, height, eave height, roof pitch, etc
2) wind load, snow load, raining condition, aseismatic requirements, etc
4) Demands for doors and windows

5) Brickwall needed or not If yes, 1.2m high or 1.5m high? or other?

6) Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; If not, the metal steel sheets will be ok.
7)Other information if necessary

Cheap High Quality Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 0Cheap High Quality Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 1

  • Product Application

Steel structures can be used for a variety of purposes, including warehouse, workshop, office, hospital, hangar, shed, commercial steel building, farm poultry broiler/layer chicken house, sheep shed, pig shed, garage and more.

Cheap High Quality Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 2

  • Technical Support

Our company can provide one-stop solution including the construction drawings and calculation with you .We have a professional technical team that offers the best steel structure building solutions depands on the specific requirements of our clients.

1 ) Experienced and skilled team of designers who has the capacity to deliver outstanding designs for your project .

2 )Design service is free of charge to all clients to ensure customer .

3 ) We look forward to delivering exceptional designs and advice for your project .

       Cheap High Quality Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 3

Cheap High Quality Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 4


  • Production Process

In the steel structure production process, we adhere to strict quality control at every stage, from the procurement of raw materials to the final product's delivery. Our technical team uses advanced production equipment and processes, aligning with international quality standards to ensure that every steel structure product possesses exceptional strength, durability, and stability. Through continuous quality monitoring and meticulous inspection procedures, we ensure that each project meets our clients' high standards, guaranteeing the safety and quality of the construction.

Cheap High Quality Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 5

  • Packaging & Shipping

We considered the fragility, weight, and potential risks during transportation of different components when loading the products into the shipping containers, and took appropriate measures to ensure the safe and efficient unloading process for the customers.

Cheap High Quality Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 6


  • Company Profile

Cheap High Quality Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 7

Cheap High Quality Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 8

Shandong Lanjing Building & Construction Co., Ltd. is a professional manufacturer for Steel structure building,Container House and Prefab house in China for more than 10 years.
Exported to 100+ countries and completed 500+ projects.

IS09001, BV, SGS, TUV audited
Lanjing Building & Construction offers comprehensive ONE-STOP services, delivering customized solutions that include Consultation, R&D, Design, Manufacturing, Installation, Overseas project supervision and after-sales support.
We specialize in creation of high-quality Steel structure Warehouse, Workshop, High-rise steel fame building and Container house for Labor camp, worker container etc.
We provide steel building to clients in the sectors of Oil & Gas, Mining, Energy dormitory, Site office, Shower container. Toilet Infrastructure and Construction projects Steel Structure built his reputation Reliability and Service.
Our factory is located in Weifang, China, with a factory area of more than 12 hectares ((120.000SOM )and a registered capital of CNY50 Million, after more than 10 years of development, we have strong technical strength and comprehensive product lines.Steel Structure has completed 500+ projects in more than 100 countries, We has built long-term partnerships with different international companies as well as organizations & government.

Main Products

Steel structure Building

Prefabricated container house

Metal Sandwich Panels

Cheap High Quality Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 9

  • FAQ

Q1: Is your company a factory or trading company?
A: We are manufacturer with foreign trade department, so you can get competitive price as well as professional service. And you are always welcomed to visit our factory at any time.

Q2: What are your main products?
A: We provide steel structure warehouse, workshop, plants,chicken house, prefabricated house, container type house, garage, aircraft hangar, sandwich panels and other construction materials. According to the requirements of different projects and clients, we will supply different designs and steel products.Customized design is available.

Q3: What's the quality assurance you provide and how do you make quality control?
A: Quality-first is our core value. LJ steel structure quality assurance team and quality control team have developed a rigorous quality inspection system based on ISO9001. Testing Laboratory guarantees qualified raw materials and high- standard product.

Q4: Do you provide installation instructions and on-site installation services?
A:Every project will provide the installation instructions, and if you need, we also would like to send our engineer to the local construction site for helping the installation work.

Q5: What should I provide to get a complete quotation?
A: Please provide information as follows:

1.Project location 5.Length (sidewall,m) 9.Window material, style,size
2.Snow load 6.Width (end wall, m) 10.Door material, style,size
3.Wind load 7.Wall Height (eave, m) 11.raining condition
4.Seismic magnitude 8.Middle column allowed or not 12.Crane needed or not
13.other information if necessary
