products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Steel Structure Warehouse
Created with Pixso.

High Quality Prefabricated Steel Building Construction Building Garage Shed Workshop

High Quality Prefabricated Steel Building Construction Building Garage Shed Workshop

Brand Name: LanJing
Model Number: S01
MOQ: 100 Square Meters
Price: US$60.00 100-4,999 Square Meters
Payment Terms: L/C,T/T
Supply Ability: 2, 500t/M
Detail Information
Place of Origin:
China
Software:
CAD, Tekla, Sketchup, Pkpm, Bim
Wall Color:
White, Blue, Optional Colors
Transport Package:
Loaded Into Shipping Container
Specification:
Q355b. Q235b
HS Code:
7308900000
Production Capacity:
2, 500t/M
Packaging Details:
Loaded into shipping container
Supply Ability:
2, 500t/M
Highlight:

prefabricated steel structure warehouse building

,

building garage shed workshop

,

high quality prefabricated steel structure warehouse

Product Description

High Quality Prefabricated Steel Structure Warehouse Building Garage Shed Workshop

The steel structure building is a product that can be customized according to each client's specific needs. If you find that the example pictures we provided are not exactly what you're looking for, even if they are completely different. No matter what kind of building you need—whether it's a prefabricated house, warehouse, workshop, factory, large or small, or multi-storey—just provide us with the necessary details or drawings of the building you require. We will create the exact design, quotation, and rendering for you as soon as possible.

Steel structures can be used for a variety of purposes, including warehouse, workshop, office, hospital, hangar, shed, commercial steel building, farm poultry broiler/layer chicken house, sheep shed, pig shed, garage and more.



Name Steel structuree building
Dimensions Length H beam: 4000-15000mm
Thickness: web plate: 6-32mm
wing plate: 6-40mm
Height 200-1200mm
Color According to customers
Size MOQ is 200 m2, width * length * eave height
Advantages

1. Lower cost but beautiful outlook.
2. High safety performance.
3. easy to assemble and dismantle
4. manufacture under complete quality control system
5. installation with instruction of experienced engineers
6. Light and Strong

7.Environmentally Friendly

8.Recyclable

Main components Base Cement and steel foundation bolts
Main frame H beam
Material Q235B, Q345B or others as buyers' requests.
Purlin C or  Z purlin: Size from C120~C320, Z100~Z20
Bracing X-type or other type bracing made from angle, round pipe
Bolt Plain bolt and High-strenth bolt
Roof & wall Sandwich panel or color plate
Door Sliding or rolling door
Window Aluminium alloy window
Surface Two lays of Anti-rust Painting or Hot Dip Galvanized
Sheet 0.5mm or 0.6mm galvanized sheet
Accessories Semi-transparent skylight belts, Ventilators,down pipe, Glavanized gutter, etc
Usages

1. Steel structure workshop, warehouse, plant, shed, storage, factory
2. Steel structure frame structure
3. Farm poultry house chicken cow sheep
4. Portal frame products
5. High rise building project

6. Steel structure industrial building

7.Commercial steel structure building

8.Steel Structure Hangar

Packing

Steel components are packaged with iron pallets at the factory with the coding number, which is convenient for customers to unload;

Small steel structures are bundled with iron wires and hung with tags.

Fasteners are packed in wooden cases

The upper layer of the color-coated roof and wall panel is covered with plastic film, and the maintenance edge is wrapped with plastic film and labelled.

Drawing According to drawings or according to customer ' s requirement.

Design Parameters

If you need we design for you, please supply us the following parameter
together with detail size:
1) length, width, height, eave height, roof pitch, etc
2) wind load, snow load, raining condition, aseismatic requirements, etc
4) Demands for doors and windows

5) Brickwall needed or not If yes, 1.2m high or 1.5m high? or other?

6) Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; If not, the metal steel sheets will be ok.
7)Other information if necessary

High Quality Prefabricated  Steel Building Construction Building Garage Shed Workshop 0High Quality Prefabricated  Steel Building Construction Building Garage Shed Workshop 1

  • Product Application

Steel structures are adaptable and can serve multiple functions, including serving as warehouse, workshop, hangar, storage, shed, commercial buildings, office, hospital, school, steel structure farm poultry chicken house for broiler or layer, barn for sheep, cow barn, garage, and various other uses.

High Quality Prefabricated  Steel Building Construction Building Garage Shed Workshop 2

  • Technical Support

If you have drawings, welcome to share drawings with us, quoation will be done based your drawings. Our excellent design team will provide you with the plan and quotation with you according your needs.

1) Customized design is welcomed.

2) In order to give you an exactly quotation and drawings, please let us know length, width, eave height and local weather. We will quote for you promptly.

       High Quality Prefabricated  Steel Building Construction Building Garage Shed Workshop 3

High Quality Prefabricated  Steel Building Construction Building Garage Shed Workshop 4



  • Production Process

In the steel structure production process, we adhere to strict quality control at every stage, from the procurement of raw materials to the final product's delivery. Our technical team uses advanced production equipment and processes, aligning with international quality standards to ensure that every steel structure product possesses exceptional strength, durability, and stability. Through continuous quality monitoring and meticulous inspection procedures, we ensure that each project meets our clients' high standards, guaranteeing the safety and quality of the construction.

High Quality Prefabricated  Steel Building Construction Building Garage Shed Workshop 5

  • Packaging & Shipping

We considered the fragility, weight, and potential risks during transportation of different components when loading the products into the shipping containers, and took appropriate measures to ensure the safe and efficient unloading process for the customers.

High Quality Prefabricated  Steel Building Construction Building Garage Shed Workshop 6



  • Company Profile

High Quality Prefabricated  Steel Building Construction Building Garage Shed Workshop 7

High Quality Prefabricated  Steel Building Construction Building Garage Shed Workshop 8

Lanjing Group is a professional company specializing in steel structure buildings and prefabricated houses. Located in Shandong Province, China, the company covers an area of more than 12 hectares.

With over 10 years of production experience, we are a well-known steel structure manufacturer in China. Our products are sold nationwide and exported to more than 100 countries and regions.

Lanjing Group will uphold the philosophy of "Quality First, Customer Foremost," providing the best products and services to global clients. We look forward to collaborating with more international partners to jointly promote the development of the global construction industry.

Main Products

Steel structure Building

Prefabricated container house

Metal Sandwich Panels

High Quality Prefabricated  Steel Building Construction Building Garage Shed Workshop 9

  • FAQ

Q1: Is your company a factory or trading company?
A: We are manufacturer with foreign trade department, so you can get competitive price as well as professional service. And you are always welcomed to visit our factory at any time.

Q2: What are your main products?
A: We provide steel structure warehouse, workshop, plants,chicken house, prefabricated house, container type house, garage, aircraft hangar, sandwich panels and other construction materials. According to the requirements of different projects and clients, we will supply different designs and steel products.Customized design is available.

Q3: What's the quality assurance you provide and how do you make quality control?
A: Quality-first is our core value. LJ steel structure quality assurance team and quality control team have developed a rigorous quality inspection system based on ISO9001. Testing Laboratory guarantees qualified raw materials and high- standard product.

Q4: Do you provide installation instructions and on-site installation services?
A:Every project will provide the installation instructions, and if you need, we also would like to send our engineer to the local construction site for helping the installation work.

Q5: What should I provide to get a complete quotation?
A: Please provide information as follows:

1.Project location 5.Length (sidewall,m) 9.Window material, style,size
2.Snow load 6.Width (end wall, m) 10.Door material, style,size
3.Wind load 7.Wall Height (eave, m) 11.raining condition
4.Seismic magnitude 8.Middle column allowed or not 12.Crane needed or not
13.other information if necessary
