Prefabricated Steel Structure Warehouse Building Garage Shed Workshop

Prefabricated Steel Structure Warehouse Building Garage Shed Workshop

Brand Name: LanJing
Model Number: S01
MOQ: 100 Square Meters
Price: US$60.00 100-4,999 Square Meters
Payment Terms: L/C,T/T
Supply Ability: 2, 500t/M
Detail Information
Place of Origin:
China
Wall And Roof Sandwich Panel:
EPS, Rock Wool, Glass Wool, PU
Rain Spout:
PVC
Lighting:
Plane Skylight
Option:
Skylight Belt, Ventilation Fitting, Gutter, Crane
After-sales Service:
Online Technical Support,Onsite Installation
Customization:
Available
Packaging Details:
Loaded into shipping container
Supply Ability:
2, 500t/M
Highlight:

Prefabricated Steel Structure Warehouse

,

Steel Structure Warehouse Q235

,

building garage shed Workshop

Product Description

Prefabricated Steel Structure Warehouse Building Garage Shed Workshop

Steel structure buildings have excellent mechanical properties, high steel strength, good toughness and ductility, can stably bear heavy loads, and ensure safety in disasters such as earthquakes.

Its construction is efficient, prefabricated in the factory and assembled on site, which greatly shortens the cycle and reduces equipment and manpower requirements. The space is flexible, and large-span column-free space can be achieved, and the layout can be adjusted conveniently in the later stage. It is also environmentally friendly and sustainable, with less construction waste and a steel recycling rate of over 90%, which is in line with the concept of green development.

Main Structure Column/Beam Q235/Q355 Welded H Section Steel
Welding Automatic Submerged Arc Welding
Rust removing Shot blasting
Surface processing twice primer and twice finish Alkyd paint or hot dip galvanized
High strength bolt Grade 10.9
Substructure Angle brace steel Q235, process and painting
Cross bracing  round bar, steel Q235 process and pre-galvanized
Tie bar round pipe, steel Q235 process and painting or pre-galvanized
Batter brace  round bar, steel Q235 process and pre-galvanized
Ordinary bolt Galvanized bolt
Roof Purlin C channel or Z channel, steel Q235, galvanized
Roof panel (50mm~200mm) Sandwich panel , corrugated galvanized iron sheet
Transparent skylight FRP
Accessories Sealant, self-tapping screw
Edge cover Made of color steel sheet
Gutter Made of steel sheet with thickness 0.8mm, or PVC
Rainspout PVC pipe
Wall Purlin C channel or Z channel, steel Q235, galvanized
Wall panel (50~200mm) Sandwich panel , corrugated galvanized steel sheet
Accessories Sealant, self-tapping screw
Edge cover Made of color steel sheet
Ventilator Unpowered axial-flow ventilator or monitor roof
Door & Window Electric/manual rolling door/sliding door, PVC/ Aluminum alloy window
Wind Resistance Grade 12 Grades
Earthquake-resistance 8 Grades
Structure Usage Up to 50 years
customized service and personalized design are welcomed!!

Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 0Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 1

  • Product Application

Steel structures are adaptable and can serve multiple functions, including serving as warehouse, workshop, hangar, storage, shed, commercial buildings, office, hospital, school, steel structure farm poultry chicken house for broiler or layer, barn for sheep, cow barn, garage, and various other uses.

Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 2

  • Technical Support

Our company can provide one-stop solution including the construction drawings and calculation with you .We have a professional technical team that offers the best steel structure building solutions depands on the specific requirements of our clients.

We strictly follow the standards in our design to meet the requirements of different functions, ensuring the safe use of the building.

1 ) Experienced and skilled team of designers who has the capacity to deliver outstanding designs for your project .

2 )Design service is free of charge to all clients to ensure customer .

3 ) We look forward to delivering exceptional designs and advice for your project .

Based on our hard work and excellent team spirit, we will promote the promotion of our products to more countries. Quality is the soul of the enterprise, which is our consistent practice. In order to achieve win-win cooperation, we will continue to seek and implement quality management best practices and become our consumers' trusted partners.

       Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 3

Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 4



  • Production Process

We perform a strict quality control system throughout the production process, including groove checks, hole checks, pitch inspections, preheat temperature checks, steel component dimension inspections, paint film thickness checks, and more. Additionally, pre-loading quality supervision is acceptable.

Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 5

  • Packaging & Shipping

We considered the fragility, weight, and potential risks during transportation of different components when loading the products into the shipping containers, and took appropriate measures to ensure the safe and efficient unloading process for the customers.

Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 6



  • Company Profile

Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 7

Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 8

Shandong Lanjing Building & Construction Co., Ltd. is a professional manufacturer for Steel structure building,Container House and Prefab house in China for more than 10 years.
Exported to 100+ countries and completed 500+ projects.

IS09001, BV, SGS, TUV audited
Lanjing Building & Construction offers comprehensive ONE-STOP services, delivering customized solutions that include Consultation, R&D, Design, Manufacturing, Installation, Overseas project supervision and after-sales support.
We specialize in creation of high-quality Steel structure Warehouse, Workshop, High-rise steel fame building and Container house for Labor camp, worker container etc.
We provide steel building to clients in the sectors of Oil & Gas, Mining, Energy dormitory, Site office, Shower container. Toilet Infrastructure and Construction projects Steel Structure built his reputation Reliability and Service.
Our factory is located in Weifang, China, with a factory area of more than 12 hectares ((120.000SOM )and a registered capital of CNY50 Million, after more than 10 years of development, we have strong technical strength and comprehensive product lines.Steel Structure has completed 500+ projects in more than 100 countries, We has built long-term partnerships with different international companies as well as organizations & government.

Main Products

Steel structure Building

Prefabricated container house

Metal Sandwich Panels

Prefabricated Steel Structure Warehouse Building Garage Shed Workshop 9

  • FAQ

Q1: Is your company a factory or trading company?
A: We are manufacturer with foreign trade department, so you can get competitive price as well as professional service. And you are always welcomed to visit our factory at any time.

Q2: What are your main products?
A: Our main productions are steel structure buildings including warehouse, workshop, plants, factory, poultry chicken house, industrial buildings, prefabricated houses and sandwich panels.  According to the requirements of different projects and clients, we will supply different designs and steel products.Customized design is available.

Q3: What's the quality assurance you provide and how do you make quality control?
A: Quality-first is our core value. LJ steel structure quality assurance team and quality control team have developed a rigorous quality inspection system based on ISO9001. Testing Laboratory guarantees qualified raw materials and high- standard product.

Q4: Do you provide installation instructions and on-site installation services?
A:Every project will provide the installation instructions, and if you need, we also would like to send our engineer to the local construction site for helping the installation work.

Q5: What should I provide to get a complete quotation?
A: Please provide information as follows:

1.Project location 5.Length (sidewall,m) 9.Window material, style,size
2.Snow load 6.Width (end wall, m) 10.Door material, style,size
3.Wind load 7.Wall Height (eave, m) 11.raining condition
4.Seismic magnitude 8.Middle column allowed or not 12.Crane needed or not
13.other information if necessary
