Customized High Quality Prefab Steel Building Construction Building Garage Shed

Customized High Quality Prefab Steel Building Construction Building Garage Shed

Brand Name: LanJing
Model Number: S01
MOQ: 100 Square Meters
Price: US$60.00 100-4,999 Square Meters
Payment Terms: L/C,T/T
Supply Ability: 2, 500t/M
Detail Information
Place of Origin:
China
Feature:
Anti-Corrosion, Earthquake Resistance, Easy To Install, High Intensity, Recyclable, Green
Install:
Online Guidance, Support Installation
Drawing:
Design The Drawing As Your Demand
Standard:
GB, ASTM, DIN, JIS, AISI, BS
Application:
Workshop, Warehouse, Platform, Fabricated House, Farm House, Poulty Chicken House, Shed,Garage
Door:
Electric/manual Rolling Door/Sliding Door
Packaging Details:
Loaded into shipping container
Supply Ability:
2, 500t/M
Highlight:

prefab steel structure warehouse building

,

prefab building garage shed

,

steel building garage shed

Product Description

Customized High Quality Prefab Steel Structure Warehouse Building Garage Shed

Steel structure building is a new type of building structure, a structure formed by steel column, beam, bracing, and purlin, all the components are prefabricated manufactured in the workshop and ready for assembling, wall and roof materials could use single color sheet or sandwich panel, all the steel structure components connected by bolt, easy installation and quickly finished.
Steel structure warehouse has features of high fire resistance, strong corrosion resistance. Steel structure workshop is mainly refers to the main bearing component is composed of steel. Including the steel columns, steel beam, steel structure, steel roof truss.



Name Steel structuree building
Dimensions Length H beam: 4000-15000mm
Thickness: web plate: 6-32mm
wing plate: 6-40mm
Height 200-1200mm
Color According to customers
Size MOQ is 200 m2, width * length * eave height
Advantages

1. Lower cost but beautiful outlook.
2. High safety performance.
3. easy to assemble and dismantle
4. manufacture under complete quality control system
5. installation with instruction of experienced engineers
6. Light and Strong

7.Environmentally Friendly

8.Recyclable

Main components Base Cement and steel foundation bolts
Main frame H beam
Material Q235B, Q345B or others as buyers' requests.
Purlin C or  Z purlin: Size from C120~C320, Z100~Z20
Bracing X-type or other type bracing made from angle, round pipe
Bolt Plain bolt and High-strenth bolt
Roof & wall Sandwich panel or color plate
Door Sliding or rolling door
Window Aluminium alloy window
Surface Two lays of Anti-rust Painting or Hot Dip Galvanized
Sheet 0.5mm or 0.6mm galvanized sheet
Accessories Semi-transparent skylight belts, Ventilators,down pipe, Glavanized gutter, etc
Usages

1. Steel structure workshop, warehouse, plant, shed, storage, factory
2. Steel structure frame structure
3. Farm poultry house chicken cow sheep
4. Portal frame products
5. High rise building project

6. Steel structure industrial building

7.Commercial steel structure building

8.Steel Structure Hangar

Packing

Steel components are packaged with iron pallets at the factory with the coding number, which is convenient for customers to unload;

Small steel structures are bundled with iron wires and hung with tags.

Fasteners are packed in wooden cases

The upper layer of the color-coated roof and wall panel is covered with plastic film, and the maintenance edge is wrapped with plastic film and labelled.

Drawing According to drawings or according to customer ' s requirement.

Design Parameters

If you need we design for you, please supply us the following parameter
together with detail size:
1) length, width, height, eave height, roof pitch, etc
2) wind load, snow load, raining condition, aseismatic requirements, etc
4) Demands for doors and windows

5) Brickwall needed or not If yes, 1.2m high or 1.5m high? or other?

6) Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; If not, the metal steel sheets will be ok.
7)Other information if necessary

Customized High Quality Prefab  Steel Building Construction Building Garage Shed 0Customized High Quality Prefab  Steel Building Construction Building Garage Shed 1

  • Product Application

Steel structures are adaptable and can serve multiple functions, including serving as warehouse, workshop, hangar, storage, shed, commercial buildings, hotel, office, hospital, school, stadium, exhibtion hall, steel structure sports hall, steel structure farm poultry chicken house for broiler or layer, barn for sheep, cow barn, garage, and various other uses.

Customized High Quality Prefab  Steel Building Construction Building Garage Shed 2

  • Technical Support

Our company can provide one-stop solution including the construction drawings and calculation with you .We have a professional technical team that offers the best steel structure building solutions depands on the specific requirements of our clients.

1 ) Experienced and skilled team of designers who has the capacity to deliver outstanding designs for your project .

2 )Design service is free of charge to all clients to ensure customer .

3 ) We look forward to delivering exceptional designs and advice for your project .

       Customized High Quality Prefab  Steel Building Construction Building Garage Shed 3

Customized High Quality Prefab  Steel Building Construction Building Garage Shed 4



  • Production Process

We performs strict quality control system during the production process. Groove check,hole check,Pitch inspection,Preheat temperature checking,steel component's dimension,inspection, paint film thickness check,etc.And pre-loading quality supervision is acceptable.

Customized High Quality Prefab  Steel Building Construction Building Garage Shed 5

  • Packaging & Shipping

We considered the fragility, weight, and potential risks during transportation of different components when loading the products into the shipping containers, and took appropriate measures to ensure the safe and efficient unloading process for the customers.

Customized High Quality Prefab  Steel Building Construction Building Garage Shed 6



  • Company Profile

Customized High Quality Prefab  Steel Building Construction Building Garage Shed 7

Customized High Quality Prefab  Steel Building Construction Building Garage Shed 8

Shandong Lanjing Building & Construction Co., Ltd. is a professional manufacturer for Steel structure building,Container House and Prefab house in China for more than 10 years.
Exported to 100+ countries and completed 500+ projects.

IS09001, BV, SGS, TUV audited
Lanjing Building & Construction offers comprehensive ONE-STOP services, delivering customized solutions that include Consultation, R&D, Design, Manufacturing, Installation, Overseas project supervision and after-sales support.
We specialize in creation of high-quality Steel structure Warehouse, Workshop, High-rise steel fame building and Container house for Labor camp, worker container etc.
We provide steel building to clients in the sectors of Oil & Gas, Mining, Energy dormitory, Site office, Shower container. Toilet Infrastructure and Construction projects Steel Structure built his reputation Reliability and Service.
Our factory is located in Weifang, China, with a factory area of more than 12 hectares ((120.000SOM )and a registered capital of CNY50 Million, after more than 10 years of development, we have strong technical strength and comprehensive product lines.Steel Structure has completed 500+ projects in more than 100 countries, We has built long-term partnerships with different international companies as well as organizations & government.

Main Products

Steel structure Building

Prefabricated container house

Metal Sandwich Panels

Customized High Quality Prefab  Steel Building Construction Building Garage Shed 9

  • FAQ

Q1: Is your company a factory or trading company?
A: We are manufacturer with foreign trade department, so you can get competitive price as well as professional service. And you are always welcomed to visit our factory at any time.

Q2: What are your main products?
A: We provide steel structure warehouse, workshop, plants,chicken house, prefabricated house, container type house, garage, aircraft hangar, sandwich panels and other construction materials. According to the requirements of different projects and clients, we will supply different designs and steel products.Customized design is available.

Q3: What's the quality assurance you provide and how do you make quality control?
A: Quality-first is our core value. LJ steel structure quality assurance team and quality control team have developed a rigorous quality inspection system based on ISO9001. Testing Laboratory guarantees qualified raw materials and high- standard product.

Q4: Do you provide installation instructions and on-site installation services?
A:Every project will provide the installation instructions, and if you need, we also would like to send our engineer to the local construction site for helping the installation work.

Q5: What should I provide to get a complete quotation?
A: Please provide information as follows:

1.Project location 5.Length (sidewall,m) 9.Window material, style,size
2.Snow load 6.Width (end wall, m) 10.Door material, style,size
3.Wind load 7.Wall Height (eave, m) 11.raining condition
4.Seismic magnitude 8.Middle column allowed or not 12.Crane needed or not
13.other information if necessary
